Chevrolet Cruze Repair Manual: Hood Hold-Open Rod Replacement
Warning: Refer to Hood Hold-Open Device Warning in the Preface section.
Preliminary Procedure
Remove the radiator grille reinforcement support. Refer to Radiator Grille Reinforcement Support Replacement.
- Hood Hold Open Rod Pivot (Qty: 2)
- Hood Hold Open Rod
